Angled view of the vented power attic motor.
The XE406 has 1 speed operation.
Right side profile view of the motor showing the capacitor.
Left side profile view of the motor showing the wiring.
Angled view of the vented power attic motor.
The XE406 has 1 speed operation.
Right side profile view of the motor showing the capacitor.
Left side profile view of the motor showing the wiring.

5.1 Amp Motor for Power Attic Ventilators

$0.00
DESCRIPTION:
Replace your old motor using only a hex key and wrench to complete installation. This motor is compatible with select roof mount and gable mount vents.

This motor is compatible with VXSVR series and CX4000 series.
PERFECT FOR:
  • Home

Controls:

1 speed PSC operation

Safety:

Thermally protected

Other Features:

Reference numbers: PRE 406, A0816B2261, F0816B2541, KDE2F4707

Primary Color

White

Secondary Color

Black

Motor Details

1-Speed Thermally Protected Direct Drive PSC Motor

1/2 in. Shaft

Motor Specs

1/8 HP

Rated at 5.1 Amps

120 Volts, 60 Hz

Rated at 1,500 RPM

Unit Weight

6 lbs.

Box Dimensions

6 in. H x 6 in. W x 6 in. D

Alias SKU(s)

XE406
XE406 UPS: Plain Carton

Multi UPC Info

XE406: 047242140620
XE406 UPS: 047242133042
